Standard Features:
- Low angle
- PLC controlled cycle
- Foot pedal operated
- Adjustable Material Stops
- Up to 2" thick material
- Cycle Time: 1.75 - 2 Sec
- Tooling Included

Technical Data and Specifications:
- Router Bit: 3/8” Solid Carbide, Rough Mill
- Drill Bit: 9/64” Brad and Spur TiN-Coated Bit
- Router: 24,000 RPM, 8 A, 2 HP
- Drill: 22,000 RPM, 0.9 HP, 5.5 CFM (Intermittent)
- Electrical: 230V, 3P, 15A
- Air: 5.5 CFM at 80 - 100 PSI
- Work height: 36"
- Footprint: 27.75" x 20.5"
- Table Area: 15.75" x 23.75"
- Dust Port: 4"

- Shipping Weight: 370 LBS
- Shipping Dimensions: 43" x 41" x 56"H

Standard Features:
- 6° Low angle
- PLC controlled cycle
- Foot pedal operated
- Adjustable Material Stops
- Up to 2" thick material
- Cycle Time: 1.75 - 2 Sec
- Tooling Included

Technical Data and Specifications:
- Router Bit: 3/8” Solid Carbide, Rough Mill
- Drill Bit: 9/64” Brad and Spur TiN-Coated Bit
- Router: 24,500 RPM, 11 A, 1.75 HP
- Drill: 31,000 RPM, 4.5 A, 7/8 HP
- Electrical: 110V 15A
- Air: 2 CFM at 80 - 100 PSI
- Work height: 36"
- Footprint: 27.75" x 20.5"
- Table Area: 15.75" x 23.75"
- Dust Port: 4"

- Shipping Weight: 350 LBS
- Shipping Dimensions: 45" x 32" x 56

[U200A1014] Clamp foot w/rubber pad and set screw.

Standard Features:
- Variable speed control 0-50 feet per minute, chain drive
- 16" Saw blade 1 " arbor
- Set up for 90, 45, and 22 1/2 degree cuts
- Pneumatically operated Saw Guard
- Double V belt Drive on arbor
- Swing out supports for longer lengths
- 60" x 96" working surface
- 4" dust outlet on back of dust hood
- Built in overload protection
- 35 1/2" working height. Adjustable leveling feet.
- 50" stroke

Technical Data and Specifications
- Spindle Size: 1" Bore, 7/8-14 Threads, Left Hand Nut
- Saw Blade: 16" Diameter, 100 Tooth, TCG Grind Recommended
- Spindle Motor: 3 HP, 3600 RPM
- Feed Motor: 0.25 HP, DC
- Electrical: Options Available
- Air: 70-80 PSI, 2 CFM

Available Options
- Pneumatic hold down with 4 cylinders

Shipping Dimensions: 104" L x 97" W x 72" H
Shipping Weight: 1,500 LBS

Standard Features:
- 4" x 132" Double Sided Horizontal Edge Belt Sander
- 1-1/2 HP Abrasive Belt Drive Motor, TEFC
- 4" X 132" Abrasive Belt Size
- (2) 4" X 49" Ground Steel Platens
- (2) Bias Tilting 12" X 65" Worktables
- End Sanding Unit with 3" X 3" Drum
- (2) 4" Diameter Dust Hoods
- Wired 1-Phase 240 Volt, 60 Hz.

Shipping Dimensions: 41" X 82" X 58"H
Shipping Weight: 730 Lbs

Standard Features:
- (1) 13-Vertical Gear Driven Spindles on 32mm Centers
- 10mm Bored Collets with set screws
- (7) Right Hand, (6) Left Hand
- 60" Back Fence With (4) Stops
- (2) Spring Loaded Index Pins
- Adjustable boring depth
- Manually Actuated Boring Cycle
- Spring Return Up Stroke
- (2) Spring Operated Hold Downs
- Manual Motor Control
- Tooling Not Included

Technical Data and Specifications
- Spindle Drive Motor: 0.75 HP
- Throat Depth: 8"
- Work Surface: 20" x 48"
- Footprint: 30" x 60"
- Electrical: 120V, 1 Phase, 60 Hz
- Air: N/A

- Shipping Dimensions: 42" X 64" X 76"
- Shipping Weight: 508 LBS

Standard Features:
- 6'x12', 45° Vertical Assembly Table
- (10) Universal Clamp Cylinders & Manifold
- Clamp Arm with (5) Hold Down Cylinders
- (3) Squaring Bars on Left, Right and Bottom Sides
- Steel Table with 2" Cylinder Position Grid Pattern
- 3" Bore Clamp Cylinder Housing (706.8 LBS of force at 100 PSI)
- 10 Port Manifold with 1/4" NPT Regulator/Gage
- Adjustable pressure from 20 to 130 PSI
- Foot Treadle
- (1) Coilhose for Pneumatic Screw Gun
- Screw Gun Not Included
- 1-5/16" Clearance Under Vertical Cylinders
- Open Back Design
- (4) Material Hold Down Dogs
- (3) Adjustable Material Positioning Stops
- Usable Table Area:
- Footprint: 66" D x 165" L x 86" H

Shipping Dimensions: 170" L X 84" W X 28" H
Shipping Weight: 1770 LBS

Standard Features:
- 5'x8' Assembly Table
- 45 Degree Vertical Easel
- Squaring Bars on Left and Bottom Sides
- 1" Thick Formica Surfaced Table
- Heavy Duty Steel Frame
- Hold Down Beam with (3) Adjustable Hold Down Cylinders
- (1) Coilhose for Pneumatic Screw Gun
- Screw Gun Not Included
- Usable Table Area: 58.5" x 94.5"
- Footprint: 117" L x 48" D

- Shipping Dimensions: 120" L x 68" W x 30" H
- Shipping Weight: 1200 LBS

Standard Features:
- 5'x12' Assembly Table
- Open Back For 60" Plus Frame Height
- 45 Degree Vertical Easel
- Squaring Bars on Right, Left, and Bottom Sides
- 1" Thick Formica Surfaced Table
- Heavy Duty Steel Frame
- Hold Down Beam with (5) Adjustable Hold Down Cylinders
- (1) Coilhose for Pneumatic Screw Gun
- Screw Gun Not Included
- Usable Table Area: 58.5" x 141"
- Footprint: 165" L x 48" D

- Electrical: N/A
- Air: 100 PSI

- Shipping Dimensions: 68" X 169" X 30" H
- Shipping Weight: 1300 LBS

Standard Features:
- 5'x12' Assembly Table
- 45 Degree Vertical Easel
- Hold Down Beam with (5) Adjustable Hold Down Cylinders
- Squaring Bars on Left, Right and Bottom Sides
- 1" Thick Laminated Surfaced Table
- Heavy Duty Steel Frame
- (1) Coilhose for Pneumatic Screw Gun
- Screw Gun Not Included
- Usable Table Area: 58.5" x 141"
- Footprint: 165" L x 48" D

- Electrical: N/A
- Air: 100 PSI

- Shipping Dimensions: 68" X 169" X 30" H
- Shipping Weight: 1250 LBS

[R200T]
Standard Features:
- 1.5 HP Spindle Drive Motor, TEFC
- Foot Actuated Boring Cycle
- 14 Degree Single Spindle
- 6,100 RPM Spindle Speed
- 24" x 30" Table Area
- Adjustable Fence with (2) Stops
- Tooling Included
- Interchangeable Head with R220T

- Electrical: 110/120V, 60Hz, 20A
- Air: 80-100 PSI
- Work Height: 38.25"
- Footprint: 34.5" x 25.25"

Shipping Dimensions: 33” X 43” X 51”
Shipping Weight: 561 LBS

[H191] 1.25" Dia. rubber replacement pad for clamp foot , adhesive backed.

[H57] Replacement boring bit for R200T, & R220T series counterbore tubs.

[A171] 5-port (4-way), .25 inch female NPT inlet(s)/outlet(s).

[A38] 1/4" NPT X 5/16" Push to connect tube, Male straight.

[A64] Combination air filter/regulator lubricator unit, polycarbonate bowl, 1/4 inch NPT port, semi-auto drain, standard pressure, 40 micron, 20-130 PSI.

[U200A10] Complete Unit

Available Versions:
R19F1 Single Phase [Newer Machines]
R19F3 Three Phase [Newer Machines]
R19F3 Three Phase [Older Machines]
All versions available via download after checkout.

Available Versions:
R46 [Newer Machines]
R46 [Serial #'s 1827-2259]
R46 [Serial #'s 1826 & Below]
All versions available via download after checkout.
